  • 2017 jkur build

    SCROLL DOWN FOR COMPLETE UPGRADE LIST AND MORE PICS!



    REBEL OFF ROAD - COMPLETE JEEP JK COILOVER CONVERSION SYSTEM

    KIT INCLUDES:
    REBEL OFF ROAD - FRONT COILOVER CONVERSION SYSTEM (BOLT ON)
    - FRONT UPPER AND LOWER COILOVER MOUNTING BRACKETS
    - (2x) KING COILOVERS 2.5 12" STROKE WITH PROPRIETARY VALVING AND SPRING RATES
    COILOVER BLACK ANO

    REBEL OFF ROAD - REAR COILOVER CONVERSION SYSTEM (BOLT ON)
    - REAR UPPER AND LOWER COILOVER MOUNTING BRACKETS
    - (2x) KING COILOVERS 2.5 14" STROKE WITH PROPRIETARY VALVING AND SPRING RATES
    COILOVER BLACK ANO

    REBEL OFF ROAD - FRONT HYDRAULIC BUMP STOP CONVERSION SYSTEM (BOLT ON)
    - FRONT UPPER RECON BUMP STOP BRACKETS


    REBEL OFF ROAD EXCLUSIVE TERAFLEX LONG ARM UPGRADE FOR RECON COILOVER CONVERSION

    BORLA CLIMBER EXHAUST SYSTEM

    JE REEL FRONT 1350 DRIVESHAFT DOUBLE CARDAN STYLE SHAFT

    JE REEL REAR 1350 DRIVESHAFT DOUBLE CARDAN STYLE SHAFT

    TERAFLEX HD TIE ROD AND DRAG LINK

    TERAFLEX FALCON NEXUS 2.1 STEERING STABILIZER

    REBEL OFFROAD - REAR HYDRAULIC BUMP STOP KIT (WELD IN)

    CURRIE ANTIROCK REAR SWAY BAR KIT WITH ALUMINUM ARMS

    DIRTYLIFE ROAD KILL FULL BEADLOCK 17X9 5x5

    37X12.50X17 TOYO OPEN COUNTRY MT

    CURRIE ROCK JOCK 44
    -RockJock 44 high-pinion nodular-iron center section with thicker walls and webbing
    -Larger/stronger Dana 44 8.8 late model JK ring and pinion set
    -1350 u-joint
    -3 inch diameter, .375 wall DOM tube
    -Currie Performance 4340 chromoly inner/outer axles with 1350 u-joints
    -Heavy gauge 3/16 laser cut steel brackets
    -Upper control arm mounts include rebuildable Johnny Joints, Lower control arm mounts are 1 piece construction with integrated skid plate
    -Optimized for 4 lift kit with 5 degrees of pinion angle to reduce driveshaft angle and 5 degrees of caster for improved steering
    -65.375 inches between wheel mounting surfaces (stock JK width)
    -5 on 5 inch with 1/2 inch studs (standard JK pattern)
    -Black satin powder coat
    -ARB Air Locker

    DANA 60 REAR 40 SPLINE ROCK JOCK AXLE - CURRIE
    -STANDARD WIDTH TO MATCH ROCK JOCK 44 FRONT HOUSING
    - 40 SPLINE AXLES (SUPER HEAVY DUTY)
    - ARB AIR LOCKER (40 SPLINE)
    - 4:88 GEARS

    -1350 YOKES

    - 5 ON 5 LUG PATTERN

    ARB TWIN AIR COMPRESSOR

    ARB MANIFOLD FOR COMPRESSOR

    M.O.R.E. UNDERHOOD COMPRESSOR MOUNT

    FRONT CURRIE ANTIROCK SWAY BAR

    SPOD 6 SOURCE SYSTEM WITH LEGENDS LABEL AND ADAPTER FOR ARB COMPRESSOR

    POISON SPYDER SOLID INNER FENDERS - POWDERCOAT INNER FENDERS

    ROCKHARD 4X4 TRANSMISSION AND OIL PAN SKID PLATE

    ROCKHARD 4X4 TRANSFER CASE SKID PLATE

    ROCKHARD 4X4 GAS TANK SKID PLATE

    ROCKHARD 4X4 EVAP SKID PLATE
